TP-424 Digital amplifier
----------------------------------------------------------------------------------------------------------------------------------------------------------------------
Feature: TP-424 is a 4-channel output digital power amplifier. The novel power consumption design makes this product still free from any external equipment in the voltage range of 90V~260V in the environment where the voltage is not uniform around the world. In normal use. This product does not bring phase delay, phase distortion, crossover, and sound is more transparent, fidelity, and better positioning. It performs well in terms of higher required bass and strength.
Model£ºTP-424
System specifications:
Power 8¦¸: 600W¡Á4
Power 4¦¸: 1100W¡Á4
Bridge BRG (8¦¸): 1200 W ¡Á2
Frequency response: 20Hz-20KHz (¡À0.25dB)
Total harmonic distortion: < 0.005%
Conversion rate: 82V/us
Damping coefficient: >950¦¸
Dynamic range: ¡Ý90dB
Signal to noise ratio: >80dB
Input sensitivity: 0.775Vrms
Voltage gain: 37.8dB
Input impedance: (balance / unbalance): Balance 20K/unbalance 10K
Protection function: pressure limit, DC, short-circuit protection, boot soft start
Cooling airflow direction: air comes from the bottom of power amplifier, out from front and rear panel
Input voltage / frequency: AC-~90v-260v/50/60H
